Utica

BOILER STEAM SPARK IGNITION NAT GAS 150 mbh UTICA

PEG150BIDE MFG #: PEG150EID
BOILER STEAM SPARK IGNITION NAT GAS 150 mbh UTICA
  • AFUE Rating: 82.6 Percent
  • AGA Input Rating: 150 MBH
  • Gas Type: Natural/Propane
  • Net IBR Rating: 94 MBH
Gas Fired Boiler; Type Steam; Supply Connection 2 Inch Threaded; Return Connection 2 Inch Threaded; Gas Type Natural/Propane; Gas Connection 1/2 Inch Threaded; AGA Input Rating 150 MBH; DOE Heating Capacity 125 MBH; Net IBR Rating 94 MBH; AFUE Rating 82.6 Percent; Boiler Dimensions 17-3/8 Inch Length x 29-3/8 Inch Width x 35-7/8 Inch Height; Boiler Material Cast Iron; Ignition Type Electronic, Intermittent Pilot Control, Spark Control; Burner Type Stainless Steel; Venting Type Atmospheric; Vent Size 6 Inch; Relief Valve Details ASME Relief Valve Supplied; Pressure Rating 15 PSI; Mounting Type Floor Mount; Warranty 10 Year Limited (Non-Prorated); Options Electronic Water Feeder, Manual Reset Pressure Switch and Low Water Cut-Off, Combustible Floor Plate; Inclusions/Features Cast Iron Push Nipple, Pressure High Limit Control, Pressure Gauge, Gauge Glass, Gas Valve, Integral Draft Hood, Vent Damper; Applicable Standard ASME H, AHRI, ANSI Z223.1/NFPA 54, ANSI/ASME CSD-1, CSA (US); Input Supply Rating 120 Volt AC at 60 Hertz 1-Phase 12 Amp; Number of Burner 5; Application Residential
  • AFUE Rating
  • Gas Connection
  • Net IBR Rating
  • Gas Type
  • Warranty
  • Pressure Rating
  • AGA Input Rating
  • Type
  • Venting Type
  • Relief Valve Details
  • Supply Connection
  • Options
  • Inclusions/Features
  • Boiler Dimensions
  • DOE Heating Capacity
  • Burner Type
  • Applicable Standard
  • Ignition Type
  • Vent Size
  • Boiler Material
  • Return Connection
  • Mounting Type
82.6 Percent
1/2 Inch Threaded
94 MBH
Natural/Propane
10 Year Limited (Non-Prorated)
15 PSI
150 MBH
Steam
Atmospheric
ASME Relief Valve Supplied
2 Inch Threaded
Electronic Water Feeder, Manual Reset Pressure Switch and Low Water Cut-Off, Combustible Floor Plate
Cast Iron Push Nipple, Pressure High Limit Control, Pressure Gauge, Gauge Glass, Gas Valve, Integral Draft Hood, Vent Damper
17-3/8 Inch Length x 29-3/8 Inch Width x 35-7/8 Inch Height
125 MBH
Stainless Steel
ASME H, AHRI, ANSI Z223.1/NFPA 54, ANSI/ASME CSD-1, CSA (US)
Electronic, Intermittent Pilot Control, Spark Control
6 Inch
Cast Iron
2 Inch Threaded
Floor Mount
