DUCT FAN 4" 135cfm INLINE S&P

TD-100X MFG #: TD-100X1
  • Dimensions: 7-3/8 in W
  • Duct Size: 4 in
  • Flow Rate: 135 cfm
  • IsInactive: false
  • Motor Speed: 2096 rpm
  • Motor Type: Asynchronous
  • Series: TD-MIXVENT
  • Type: Mixed Flow
  • Voltage: 120 VAC

S&P TD-MIXVENT Mixed Flow Inline Duct Fan Turbo, 120 VAC, 4 in Duct, 135 cfm

S&P Inline Duct Fan Turbo, Mixed Flow, Series: TD-MIXVENT, 120 VAC, 33 W, 135 cfm, 4 in Duct, 11-15/16 in Length, 104 deg F, 60 Hz, Asynchronous Motor, 2096 rpm Motor, Ball Bearing, 7-3/8 in W

The S&P TD-MIXVENT series of in-line duct fans have been specially designed to maximize the airflow performance with minimal noise levels within the smallest and most compact housing size. This makes the TD-MIXVENT series the ultimate solution for small to medium sized ventilation installations, which require a high airflow to pressure ratio and occupy only the minimum space possible. Example: false ceiling voids, cabinets and many other limited space environments.

  • Voltage
  • Duct Size
  • Power Rating
  • Motor Type
  • Bearing Type
  • Flow Rate
  • Type
  • Temperature Rating
  • Dimensions
  • Motor Speed
  • Series
  • Length
  • Frequency Rating
  • IsInactive
120 VAC
4 in
33 W
Asynchronous
Ball
135 cfm
Mixed Flow
104 deg F
7-3/8 in W
2096 rpm
TD-MIXVENT
11-15/16 in
60 Hz
false
